1. To position the Monitors:
• To adjust the angle of the Monitor Arms, use the Hex Key to loosen the two
Screws at each of the Monitor Arm joints. Position the Monitors as desired,
and use the Hex Key to tighten the Screws and lock the Monitors into
position. (Figure 25)
Figure 25
• To tilt the Monitors, use the Hex Key to loosen the Screw in the sides of the
VESA Adapters. Position the Monitors as desired, and use the Hex Key to
tighten the Screws and lock the Monitors into position. (Figure 26)
Figure 26
User Manual
Hex Key
19
Hex Key
