3. Affix the Rubber Pads to the bottom of the Grommet-Mounting Adapter.
(Figure 10)
Figure 10
Grommet-
Mounting
Adapter
Rubber Pads
4. Slide the Mounting Cover over the Column and screw the Column into the top of
the Grommet-Mounting Adapter. (Figure 11)
Figure 11
Grommet-Mounting
5. Use the hex side of the Hex Key Screwdriver to tighten the two Hex Screws in the
Grommet-Mounting Adapter, and push down the Mounting Cover so that it sits
flush with the Grommet-Mounting Adapter. (Figure 12)
Figure 12
Column
Mounting
Cover
Grommet-Mounting
Adapter
User Manual
Column
Mounting
Cover
Adapter
11
Hex Key Screwdriver
