The total number of channels is not affected by decoding channels. For IP
cameras, the system uses hard decoding. The total number of channels is
influenced by decoding channels. For different work modes (set in
list), the channels you can use are different, the local board channels must be
the first available channels. If you disable hard decoding via
you can't output real-time video of the IP cameras to TV Wall.
*Note: A camera can only be selected once per Video Window/Matrix Group.
【Switch Video Interval(sec)】Set interval that each window shows
cameras circularly when there is more than one camera selected to be
viewed in it.

Display setup

2.6.2
【Display Group】 System operator can set a groups of cameras to
display for fast preview, including its display mode and cameras. Up to 16
groups can be set.
【Video Split Mode】Set the split mode, the split mode is same as the
main window's display split mode. There are 1, 4, 9, 13, 16, 20, 25, 28, 33, 36,
40, 49 and 64 partition modes.
【Video Window】 【Display Camera in the window】After selecting
video split mode, there will be corresponding windows, select one camera to
be shown per window. The windows may include up to 64 cameras, when the
total number of local channels and IP cameras is less than 64, some channel
windows will not have an image and be designated with a black window.
*Note: One camera is only shown in one window once, but each camera can display any window
discretionarily. E.g.: The 1
displayed in window2. When the 1
camera will change to window 1 automatically.
st
camera has been displayed in window1, and the 2
st
camera is changed to be displayed in window2, the 2
48
DVR Server Manual ver.6.05/rel.120909
IP Camera
nd
camera has been
IP Camera
list,
nd
