cameras of the local board card, IP Cameras are not included. For IP Camera,
you should set it remotely in
【Camera Description】Input descriptions for easy identification.
【Camera Type】Select camera type from drop-down list. Users can
choose from PAL and NTSC.
【Camera】Enable or disable selected camera.
【Remote Frame Rate(fps)】Set the frame rate of the client.
【Bit Rate】Set recording mode. Variable Bit Rate (VBR) or Constant Bit
Rate (CBR) Recording.
VBR allows each frame to be recorded at a dynamic bit rate
depending on the image complexity, activity and color.
CBR allows each frame to be recorded at a fixed bit rate, regardless
the scene activity. In many cases, this limits detail (resolution). The benefit of
CBR is its ability to accurately estimate the total video capacity.
【Frame Rate(fps)】Set the recording rate for selected camera. For
Frames per Second (fps), the frame rate should be from 1 to 30 fps.
image size is set ―704*576‖, the frame rate should be set around 1 to 15
frame (only for HC
【Remote Image size】Select image resolution to be transmitted to
clients. When you set the
is not available, program will select it as CIF automatically because DVR
board does not support dual stream when it records with 4CIF resolution (only
for HC Series).
【Image Quality】Sets the quality of the image to be recorded. Select
from Poorest, Poor, Medium, Very good and Best.
Click this button to view advanced setup for video quality, you can
set I B P frame and maximum bit rate.
(Note: If you are not familiar with these features, we advise you not to change
Recommended setup:
IP Camera
Series)
【Image Size】 as 4CIF (704*576), this configuration
DVR Server Manual ver.6.05/rel.120909
setup.
36
While
them)
