Optiview VR Enterprise User Manual page 44

32
24
Less or Equal to16
【OSD Date】Select whether to display the OSD date on the screen or
not. When you select ―Not‖, the date will not be displayed on the screen of the
corresponding channel.
【Masking Bitmap File】Watermark function, the logo picture must be
edited ad 128*128 pixels file size and saved in bmp format.
【Record Days】This section allows users to determine how long the
record data of each camera should be kept by the system. The maximum
duration for on-line storage is 120 days. Users can select exact number of
days, or can select ―auto‖ mode. If ―auto‖ is selected the system will
auto-delete the oldest recorded data when there is not enough space.
*NOTE: If there is not enough space on the HDD, the system will delete the recorded data
according to the length of saving time of each camera. Eg: there are four cameras, the 1
nd
saves 2 days, the 2 camera saves 5 days, the 3
will set "auto" mode. If there is enough space, the 4
HDD, when there is not enough space, the system will delete data automatically. If the 4
camera‟s record data has been saved more than 10 days, the system will delete the 4
th
camera‟s record data has been saved less than 10 days, but the 3
data, if the 4
more than 10 days, system will delete the 3
record data saving 10 days, the data that is saved could be less than 10 days. System will delete
the recorded data from the earliest date.
【OSD Contrast】Set OSD displaying brightness & position. An ―auto‖
item in OSD Contrast's drop-down list will make OSD suit the background's
color automatically.
【Copy Setup to】Set other cameras with the same setup.
Notes:
1. The unit of the swap file should be in MB. The range is 2 to 50.
2. Set the position and contrast of the date shown on the screen. Sometimes the date cannot be
clearly seen for its color is similar to the background. You can change its position or color when
this happens.
3. Image size is the format used when recording. Remote image size is the format used when
these images are transmitted to client sites.
4. Remote Frame Rate, Remote image size and Remote Quality are the parameters of the client
side. When the server‟s image size is set as "704*576 (12fps)", these three items are not in effect,
and the client‟s parameters will be the same as the server. When the server‟s resolution is set to
others (except "704*576(12fps)"), if Remote image size is set as "Same as Rec", Remote frame
DVR Server Manual ver.6.05/rel.120909
DCIF
CIF
DCIF
CIF
4CIF
DCIF
CIF
rd
camera saves 10 days, and the 4
th
camera‟s record data will be saved on the
rd camera‟s data. So, even if you set the 3
38
st
camera
th
camera we
th
th
camera‟s
rd
camera‟s data is
rd camera‟s
