recording.
【Selected Group】Select group number.
【Sensor Type】Select NC or NO alarm type.
【Alarm Write log】Select to write to alarm log or not.
【Alarm Action】Select system alarm linkage mode when an alarm
stops. ―Stop Immediately‖ means the system will stop alarm immediately after
the alarm driver stops an alarm. ―Do Not Stop‖ means the system will not stop
the alarm after the alarm driver stops an alarm. ―Wait‖ means the system will
stop alarm at your setting time after the alarm driver stops an alarm.
【Sensor input】Add sensor to selected group.
【Tie to cameras】Set cameras that are to be related to this sensor
group. They will start recording and connect to the preset remote network
client automatically when there is an alarm. These cameras just include the
cameras of the local board card; IP Cameras are not included. IP cameras
are set remotely in
【Tie to Relay Output】Add alarm devices (alarm out port) to this group
such as a siren or light. All connecting devices will send an alarm message
when there is an alarm.
Schedule Setup (Example for below figure)
1. ―Check Alarm‖ (red): DVR System responds to sensors during this time.
(00:00 to 23:59 from Sun. to Sat.)
2. ―Not Check‖ (gray): DVR System doesn't respond with sensor during this
time.
Note: If you set a camera in several groups, only the last setup is available.
IP Camera setup.
