Fluke Calibration 5730A Operator's Manual page 238

5730A
Operators Manual
2820 A11: Fine Adjust Channel Fault
2821 A8/A11: +11/22 V DC Zero Estimate Fault
2822 A8/A11: -11/22 V DC Zero Estimate Fault
2823 A11: Could not Estimate +11 V Or 22 V Gain
2824 A11: Could not Estimate 6.5 V Or 13 V Ref
2825 A11: Could not Est 6.5 V Or 13 V Buf Ref
2826 A11: A/D Overload Fault
3100 A14: 8255 Control Word
3101 A14: 8255 Port A Fault
3102 A14: 8255 Port B Fault
3103 A14: 8255 Port C Fault
3104 A15: HV Oven Regulation Fault
3105 A15: HV I Oven Regulation Fault
3106 A15: DC HV Amp Noise Fault
3107 A15: DC HV Amp Offset Fault
3108 A15: DC HV Amp Gain Fault
3109 A15: HV +DC Preamplifier Fault
3110 A15: HV +DC Series Pass & Current Fault
3111 A15: HV +DC High Voltage Output Fault
3112 A15: HV +DC Ref/Error Amplitude Fault
3113 A15: HV -DC Preamplifier Fault
3114 A15: HV -DC Series Pass & Current Fault
3115 A15: HV -DC High Voltage output Fault
3116 A15: HV -DC Reference/Error Amp Fault
3117 A14/A15: HV +DC Current Error Amp Fault
3118 A14/A15: HV -DC Current Error Amp Fault
3119 A14/A15: HV +DC Current Abs. Value
3120 A14/A15: HV -DC Current Abs. Value
3122 A14/A15: HV AC 1 KHZ, Preamp Fault (lo)
3123 A14/A15: HV AC 1 KHZ, Preamp Fault (mid)
3124 A14/A15: HV AC 1 KHZ, Preamp Fault (hi)
3125 A14/A15: HV AC 100 HZ, Preamp Fault (lo)
3126 A14/A15: HV AC 100 HZ, Preamp Fault
A-16
3100-Level Faults: Self Diagnostics (High Voltage)
