The shifts of references and outputs are given both as absolute shifts in V, A, or ohms,
and also (for non-zero magnitudes) as shifts relative to the previous value, in parts per
million (ppm) or percent (%).
The specified accuracy for the output is also shown, and the ratio of the shift to that
accuracy in percent.
The Calibration Shift report file name is CSyymmdd.CSV, where yymmdd is the date
today. For example, a calibration shift report compiled on October 28, 2013 would be
saved to CS131028.CSV.

Calibration Check Shift Results

The Calibration Check report presents changes in the magnitude of self-correction
generated by calibration check. Calibration check uses internal standards rather than
external standards as the basis for comparison, and does not make permanent changes to
calibration constants. This report is available only after a calibration check has been
performed and until the Calibrator is reset. The report contains the subsequent
information, and is shown below:
•
Heading that shows the date and time the report was saved and user report string
•
Modules present (installed or attached)
•
Most recent calibration dates and temperatures
•
Values of externally-calibrated internal references
•
DC voltage output shifts for each range
•
AC voltage output shifts for each range
•
AC and dc current output shifts for each range
•
Resistance shifts for each value
•
5725A Boost Amplifier output shifts (if attached). The calibration report file name is
CKyymmdd.CSV, where yymmdd is the date today.

Raw Data Results

This report gives the values for the internally stored correction factors (calibration
constants), and is useful primarily for our service centers.
