Fluke Calibration 5730A Operator's Manual page 170

5730A
Operators Manual
LCOMP_52120?
Description
Parameter
Response
Example
LIMIT
Description
Parameter
Example
LIMIT?
Description
Response
Example
*LRN?
Description
Parameter
Response
Example
6-36
Table 6-5. Commands (cont.)
Sequential command. Returns the current state of inductance compensation for
attached 52120As.
None
String
LCOMP_52120?
Returns ON if LCOMP is enabled.
Sequential command, ignored if not in remote.
Sets the maximum permissible output magnitudes, negative and positive. Both
parameters must be present, and the units must be none, volts, or amps. The units must
not conflict. If no units are specified, V is assumed.
1. Positive limit value with optional multiplier and optional unit.
2. Negative limit value with optional multiplier and optional unit.
LIMIT 1.8 A, -1.2 A
Sets the limit for ac and positive dc current to 1.8 A, and negative dc current to -1.2 A.
Sequential command.
Returns the programmed output magnitude limits for voltage and current.
(Float, float, float, float)
1. Positive voltage limit value
2. Negative voltage limit value
3. Positive current limit value
4. Negative current limit value
LIMIT?
Returns: +2.2000000E+02,-1.0000000E+02,
+1.8000000E+00,-1.2000000E+00if the programmed voltage range is -100 V to 220 V,
and the programmed current range is -1.2 A to 1.8 A.
Sequential command.
Provides the current setting of the Calibrator. The response to this command is a string
that recreates the state of the subsequent settings when returned to the Calibrator:
Output value Whether the wideband AC Module is on
Operate/standby Whether an auxiliary amplifier is on
Guard Range lock
Sense Two-wire compensation
Output limits
None
(String) A string that enables the settings that were set at the time of the *LRN?
command.
SETMFC
'00000000000024400000000000408F4000000000000024400000000000002440000000
0000000000000000000030914000000000003091C00000000000807640000000000080
76C000000000000000000000000000000000000000000000000000000000000000000B
000158010000000E080000'
Phase lock
Phase shift
Offset
Scale
