Fluke Calibration 5730A Operator's Manual page 160

5730A
Operators Manual
CAL_TEMP
Description
Parameter
CAL_TEMP?
Description
Parameter
Response
CAL_USB
Description
Parameter
Example
CAL_WBFLAT
Description
Parameter
Example
6-26
Table 6-5. Commands (cont.)
Sequential command, ignored if not in remote.
Sets the temperature for calibration. This should be done before sending CAL_REF,
CAL_WBFLAT, CAL_WBGAIN, or CAL_CHK commands. Once set, the temperature is
used for all calibration activities until it is changed. If the temperature is not set before a
calibration activity, the Calibrator uses a default of 23.0 °C.
Temperature in degrees C.
Sequential command.
Returns the previous ambient temperature setting used for a particular calibration
procedure.
B5725, CAL, WBFLAT, WBGAIN, or CHECK
(Float) Temperature in degrees C.
Overlapped command. Saves a calibration report to a USB thumb drive connected to the
front panel USB host port.
CAL (Output change report for calibration)
CHECK (Output change report for calibration check)
RAW (A list of all calibration constants)
CAL_USB RAW
Overlapped command, ignored if not in remote.
Does Wideband AC Module (Option 5700-03) flatness calibration. There are two different
calibration procedures for the wideband module- gain and flatness. Wideband gain is to
be done at every calibration cycle. Wideband flatness is needed only during full
verification, recommended every two years. For reference, the manual procedure for
wideband flatness calibration is in Chapter 7.
After sending a CAL_WBFLAT START command, the controller must adjust the
Calibrator output with the INCR command until it matches the calibration voltage, then
inform the Calibrator of the fact by sending a CAL_WBFLAT NULL command. A series of
points to test is selected automatically by the software. After each CAL_WBFLAT NULL
command, determine the calibration setting by sending an OUT? command.
START (Starts flatness calibration, sources the first point)
NULL (Calculates flatness constant, sources the next point)
STORE (Stores wideband flatness constants into non-volatile memory)
CAL_TEMP 24.6
CAL_WBFLAT START
(Connect to external standard as in Chapter 7)
OPER
INCR (Enough to get the Calibrator output correct)
CAL_WBFLAT NULL
(Repeat the preceding two commands for each calibration point. CAL_NULL
automatically sources the next calibration point. When OUT? returns 0,V,0, all points
have been calibrated.)
CAL_WBFLAT STORE
