The following describes how to program the timer settings
that appear under PARTITION 1.
Entry Delay
(0310)
(Default = 32 seconds) This setting determines how much
time (32 - 240 seconds) users have to disarm the system
(after entering the armed premises through a designated
delay door) to avoid causing an alarm.
œÌi
For UL Listed residential installations, the Entry
Delay must be set to 45 seconds or less.
To set the Entry Delay:
With the display showing ENTRY DELAY nnn
SECONDS (current setting), enter the desired time
value (32 - 240 using 8-second intervals).
The display flashes the entered setting. Press
the display shows the new setting.
Exit Delay
(0311)
(Default = 64 seconds) This setting determines how much
time (48 - 184 seconds) the user has to leave the premises
through a designated delay door (after arming the system)
without causing an alarm.
œÌi
For UL Listed residential installations, the Exit
Delay must be set to 60 seconds or less.
To set the Exit Delay:
With the display showing EXIT DELAY nnn
SECONDS (current setting), enter the desired time
value (48 - 184 using 8-second intervals).
The display flashes the entered setting. Press
the display shows the new setting.
Extended Delay
(0312)
(Default = 4 minutes) This setting determines how much
time (1 - 8 minutes) the user has to enter or exit the
premises through a designated extended delay door without
causing an alarm.
œÌi
For UL Listed systems, Extended Delay shall not
be used.
To set the Extended Delay:
With the display showing EXTENDED DELAY nn
MINUTES (current setting), enter the desired time
value (1 - 8).
The display flashes the entered setting. Press
the display shows the new setting.
(Timers—Partition 1)
ƒ and
(Timers—Partition 1)
ƒ and
(Timers—Partition 1)
ƒ and
Siren Timeout
(0313)
(Default = 4 minutes) This setting determines how long
sirens sound (1 - 30 minutes) if no one is present to disarm
the system.
œÌi
For UL Listed systems, Siren Timeout must be set
to 4 minutes or more.
To set the Siren Timeout:
With the display showing SIREN TIMEOUT nn
MINUTES (current setting), enter the desired time
value (1 - 30).
The display flashes the entered setting. Press
the display shows the new setting.
Touchpad Options Menu
The TOUCHPAD OPTIONS menu lets you set up touchpad
panic and arming operation.
The following describes how to program the touchpad
option settings that appear under PARTITION 1.
Fire Panic (Touchpad Options—Partition 1)
(0400)
(Default = on) This setting determines whether touchpad
fire panic buttons are enabled (on) or disabled (off).
To change the Fire Panic setting:
With the display showing FIRE PANIC OFF/ON
(current setting), press
flashes the entered setting. Press
shows the new setting.
Aux. Panic (Touchpad Options—Partition 1)
(0401)
(Default = on) This setting determines whether touchpad
auxiliary panic buttons are enabled (on) or disabled (off).
To change the Auxiliary Panic setting:
With the display showing AUXILIARY PANIC OFF/
ON (current setting), press
The display flashes the entered setting. Press
the display shows the new setting.
Police Panic (Touchpad Options—Partition 1)
(0402)
(Default = on) This setting determines whether touchpad
police panic buttons are enabled (on) or disabled (off) on.
To change the Police Panic setting:
With the display showing POLICE PANIC OFF/ON
(current setting), press
flashes the entered setting. Press
shows the new setting.
Programming the Panel
(Timers—Partition 1)
ƒ and
1 (off) or 2 (on). The display
ƒ and the display
1 (off) or 2 (on).
ƒ and
1 (off) or 2 (on). The display
ƒ and the display
23
