13.0 Horizon Compact Plus Management
The Horizon Compact Plus system can be fully managed locally or remotely. Horizon Compact Plus
supports Telnet access, SNMP management and a Web interface accessible through the IP network.
The entire Command Line Interface (CLI) command set is available through Telnet. The entire list of
system parameters is available through SNMP access. The Web interface provides access to system
configuration and performance parameters. In-band and out-of-band management options are available.
Refer to Volume 2 for detailed system management procedures.

13.1 Alarms List

Use the CLI command get alarms to display a list of active alarms. Alternatively, alarms are listed on the
Alarms page of the Web interface. Active alarms are clearly indicated.
The following list shows the various alarms available:
Explicit Authentication Failed
Ethernet Port1 Link Down
Ethernet Port2 Link Down
Ethernet Speed Alarm
Dropped Ethernet Frame Threshold Exceeded
Bandwidth Utilization Threshold Exceeded
Modem hardware fault
Modem receiver loss of signal
Modem SNR below threshold
Modem programming error
Modem transmitter loss of sync
Modem equalizer stress above threshold
Radio RSL Below Threshold
SNTP Servers Unreachable
RLS Shutdown Activated
Tx power detector below threshold
Radio current out of limits
Horizon Compact Plus Release 1.0.1
TempComp cal table not available
Radio temperature out of limits
ATPC Config Mismatch
ATPC auto-disabled (coordinated power exceeded)
RLS Mismatch
Frequency File invalid
AAM Config mismatch
AAM running on lowest modulation
Synthesizer Unlock
Partner Redundancy Mode Mismatch
Partner Configuration Mismatch
HSB Active on Secondary
HSB Override by User
HSB Cross Link Active
Hitless AAM Config Mismatch
Hitless AAM running on lowest modulation
Hitless AAM event
Wireless Ethernet Product User Manual – Volume 1
