4.0 Installation Requirements
Note: For more information on installation and cabling, refer to DragonWave Technical Note:
HC-TN-001.4 Horizon Compact Plus PonE.
Various installation kits are available. Use the following key to build the desired kit part number:
*** Use ECO #1407 green jumper wire to connect 48V RTN to PonE ground internally when site has
grounded 48 VDC return (positive)
Table 4-1 lists all the current ordering configurations, for various parts of the world.

Table 4-1 Parts Required

Kit Description
Horizon Compact Plus, No connectors AC Install Kit (N. America)
Horizon Compact Plus, No Connectors AC Install Kit (Europe )
Horizon Compact Plus, No Connectors Half AC, Half DC Install Kit (N. America)
Horizon Compact Plus, No Connectors Half AC, Half DC Install Kit (Europe )
Horizon Compact Plus, No Connectors DC Install Kit (Global)
Horizon Compact Plus, Rugged No connectors AC Install Kit (N. America)
Horizon Compact Plus, Rugged No Connectors AC Install Kit (Europe )
Horizon Compact Plus, Rugged No Connectors Half AC, Half DC Install Kit (N. America)
Horizon Compact Plus, Rugged No Connectors Half AC, Half DC Install Kit (Europe )
Horizon Compact Plus, Rugged No Connectors DC Install Kit (Global)
HC+, Indoor PonE, No connectors AC Install Kit (N. America)
HC+, Indoor PonE, No connectors AC Install Kit (Europe )
HC+, Indoor PonE, No onnectors DC Install Kit (Global)
HC+, Indoor PonE, Rugged No connectors AC Install Kit (N. America)
HC+, Indoor PonE, Rugged No connectors AC Install Kit (Europe )
HC+, Indoor PonE, Rugged No onnectors DC Install Kit (Global)
Horizon Compact Plus Release 1.0.1
CODE DESCRIPTION
INK Installation Kit
R1 Horizon Compact Plus Release 1
CONNECTOR OPTIONS
HCN No Connectors or Cables
HCC Copper Connectors, Out-of-Band Mgmt
HCI Copper Connectors, In-band Mgmt
Military connector, Copper cables
HCM
HCF Optical Fibre Interface
POWER OPTIONS
AC Alternating Current
DC Direct Current ***
AD ½AC ½DC
LOCATION OPTIONS
NA North America
EU Europe
GL Global
Part Number
A-INK-CPN-AC-NA-R1
A-INK-CPN-AC-EU-R1
A-INK-CPN-AD-NA-R1
A-INK-CPN-AD-EU-R1
A-INK-CPN-DC-GL-R1
A-INK-CPNA-AC-NA-R1
A-INK-CPNA-AC-EU-R1
A-INK-CPNA-AD-NA-R1
A-INK-CPNA-AD-EU-R1
A-INK-CPNA-DC-GL-R1
A-INK-CPNI-AC-NA-R1
A-INK-CPNI-AC-EU-R1
A-INK-CPNI-DC-GL-R1
A-INK-HNIA-AC-NA-R1
A-INK-HNIA-AC-EU-R1
A-INK-HNIA-DC-GL-R1
