Required Action
Configure the radio parameters
Horizon Compact Plus Release 1.0.1
Steps
This command leads you through the steps to configure the radio band, system
mode and frequency channel.
Sequence:
set radio config press Enter
The system responds:
#Press 'Ctrl-X' to exit config process
#Press 'Enter' to retain previous value
Radio Bands Available in the system :
freqNone
fcc18_1_20_R5
fcc18_1_40_R5
test18_1_7_R5
braz18_1_28_R5
Enter new radio band [fcc18_1_50_R5]:
System modes available in the system :
cw_test
hy50_198_32qam
hy50_329_256qam
Enter new system mode [hy50_285_128qam]:
Available frequencies for the radio band:
Index TX RF
1 17765000
2 17815000
3 17865000
4 17915000
5 17965000
6 18015000
7 18065000
8 18115000
All Frequency in kHz
Enter programmed frequency [2]:
Would you like to save MIB ? Enter Y(Yes) or N(No):y
Apply the setting to system immediately. This operation may cause the
loss of current connection!
Continue? Enter Y(Yes) or N(No)n
Note: Answering "Yes" (y) to the above request will cause any
changes to take effect immediately and you will not get the prompt
to save mib and reset system.
Save MIB and reset system for changes to take effect.
Radio Band selected :fcc18_1_50_R5
System mode set to :hy50_285_128qam
Save MIB and reset system for changes to take effect.
Programmed frequency selected:
Index TX RF
2 17815000
All Frequencies in kHz
Save MIB and reset system for changes to take effect.
fcc18_1_10_R5
fcc18_1_30_R5
fcc18_1_50_R5
braz18_1_14_R5
braz18_1_56_R5
hy50_66_qpsk hy50_154_16qam
hy50_241_64qam hy50_285_128qam
hy50_351_256qam
RX RF
19325000
19375000
19425000
19475000
19525000
19575000
19625000
19675000
RX RF
19375000
