6.2.9 Changing NOC and Admin User Passwords
The Super User may change a noc or admin user's password, by over-writing or re-entering the user's
name and password using the same process for adding a new user.
6.2.10

Logging Out

When accessing the system via Telnet, log out of the system by using the CLI command lo.
When accessing using the Web browser, closing the browser will log you out of the system.
6.2.11

Session Time Out

After 10 minutes of inactivity, Horizon Compact Plus units will automatically terminate the login session.
6.2.12 Recovery of IP Address and Serial Numbers
In the event that the Horizon Super User name and password, or IP address has been lost, forgotten, or
misconfigured, you will need to contact DragonWave (support@dragonwaveinc.com). DragonWave
Technical Support will provide the Merlin recovery utility that, using a proprietary protocol, can recover the
configured IP address parameters and/or reset the Super User name, Super User password and IP
address parameters to the factory default values (energetic, wireless; 192.168.10.100, 255.255.0.0). In
addition it reports the system serial number.
The Merlin utility runs on a PC running the Windows operating system and requires a one-time-use
recovery key provided by DragonWave. Proof of ownership and proof of authority must be provided
before the key will be issued. When Merlin is invoked, the Horizon unit responds with the required
information, which is saved in a text file, located in the same directory as the Merlin application.
6.3

Using the Web interface

The Horizon Compact Plus Web interface is enabled by default.
Open a Web browser and, in the "Address" or URL field at the top of the page, enter the IP address of the
Horizon Compact Plus unit (default is 192.168.10.100) and press Enter. If your laptop or PC has been
correctly set up, you will be prompted for the user name and password. Type in the Super User name and
password. The same security access option selected when you purchased the system is also applied to
the Web interface. For the DragonWave default option the Super User name is "energetic" and the
password is "wireless".
The web page interface is intuitive and can be used to configure most of the basic configuration
requirements and also some advanced features. However, it cannot be used to configure all features (e.g.
system user accounts). Its best use is for monitoring the status of systems that are already configured
and for making changes to the existing configuration. See Volume 2 of this manual to see a detailed
description of the web interface.
