Figure 10-3 Main and Side Lobes
Figure 10-4 Typical main lobe coverage using 23 GHz Radio with 24" dish antenna
Table 10-2 Approximate size of beam at destination
Beamwidth
(18/24" antenna)
2˚
1.3˚ (36" antenna)
(48" antenna)
1˚
Horizon Compact Plus Release 1.0.1
1 km
3 km
35m
105m
23m
68m
18m
54m
Preparing for Alignment
5 km
8 km
175m
280m
114m
182m
90m
144m
Wireless Ethernet Product User Manual – Volume 1
57
10 km
350m
227m
175m
