Every video output device has an area where video is not displayed. This area is called
the bezel. Bezel compensation takes this area into account when a single video source is
divided and displayed on multiple output devices.
1.
Check the output on the video wall and identify any misaligned edges. For best
results, it is recommended to use a static video pattern for this test.
In the illustration on the left, we have a 2x2 video wall without bezel compensation.
Note the ZeeVee logo is not aligned correctly across all four displays. On the right,
bezel compensation is used to fix the issue.
Without Bezel Compensation
It is recommended that when the video wall is set up for the first time, that these
values be set to zero. Bezel compensation can be changed at any time.
Bezel compensation is always measured in pixels.
2.
Left click the edit video wall button in the lower left corner of the desired wall.
Bezel Compensation
With Bezel Compensation
31
Basic Operation
