10. Define the system device. The DEV statement parameters are explained in
part III. section 4.2. 1. In sections 2 and 3 one example is used throughout
the installation procedures. The user. however. must supply his own param-
eters according to the equipment available.
LUN 01 HT DP C
1.
E Q UU 10 DT 853 CLR N
11. IUP types:
A IUP 006 READY FOR INPUT
12. Re spond by typing:
DEV
and press FINISH
13. Define the logical unit containing the MSOS binary source.
LUN.QZ HT MT C Q. E Q UU 00 DT 657
14. IUP types:
A IUP 006 READY FOR INPUT
Steps 15 through 20 are optional; the user may proceed directly to step 21.
15. Respond by typing:
DEV
and press FINISH
16. Define the logical unit for the card punch.
LUN 03 HT CP C
~
E
1 uu
00 CDT 3446
17. IUP types:
A IUP 006 READY FOR INPUT
18. Respond by typing:
DEV
and press FINISH
19. Define the logical unit for the line printer.
LUN 04 HT PR C Q E
1.
uu
00 DT 512
20. IUP types:
A IUP 006 READY FOR INPUT
21. Instruct IUP to install the interim library on the system device defined in step
10 (part III. section 4.2.11).
II -3-2
INST LIB 01 DUMP UNIT.Q! EDITION IL DN dn MFC yyy MSC xx EXID
exid
60410800 D
