Controller Tag
EventSeqCmd.Trigger
EventSeqCmd.ClientID
EventSeqCmd.Client[x].Cou
nt
EventSeqCmd.Client[x].Cmd
[x].Sequence
EventSeqCmd.Client[x].Cmd
[x].Error
EventSeqReady
ServerStatusTrigger
ServerStatus.MNET.Reques
ts
ServerStatus.MNET.Respon
ses
ServerStatus.MNET.ErrSent INT
ServerStatus.MNET.ErrRec
ServerStatus.MBAP.Reques
ts
ServerStatus.MBAP.Respon
ses
ServerStatus.MBAP.ErrSent INT
ServerStatus.MBAP.ErrRec
ProSoft Technology, Inc.
September 20, 2018
Data Type Description
BOOL Set the value of this tag to 1 to trigger the Event
Sequence Command block request.
Specifies Client (0 to 29) to request status data from.
INT
INT Number of Event Sequence Commands executed by
the specified Client for which status has not yet been
retrieved
INT Sequence number for each Event Sequence
command
INT Error code for each Event Sequence command:
0=success, 1=failure
DINT One bit for each Client, indicating which Clients have
Event Sequence commands with unretrieved status
data: 0=no status data available, 1=status data
available for retrieval
BOOL Set to 1 to trigger the Server Status block request.
INT This counter increments each time an MNet (port
2000) request is received.
INT This counter increments each time an MNet (port
2000) response message is sent.
This counter increments each time an MNet (port
2000) sends an exception response to Client.
Example: Client sent illegal Modbus Data location
address.
INT This counter increments each time an MNet (port
2000) receives a bad command. Example: Client sent
illegal function command.
INT This counter increments each time an MBAP (port
502) request is received.
INT This counter increments each time an MBAP (port
502) response message is sent.
This counter increments each time an MBAP (port
502) sends an exception response to Client. Example:
Client sent illegal Modbus Data location address.
INT This counter increments each time an MBAP (port
502) receives a bad command. Example: Client sent
illegal function command.
