Name
WriteDataBlkCount
RBTSremainder
WBTSremainder
PassThru
IPsetPending
IPgetPending
InitOutputData
FaultCode
CheckInitialization
StatusSeqIndex
The LastRead tag stores the latest Read Block ID received from the module. The
LastWrite tag stores the latest Write Block ID to be sent to the module. The
BlockIndex tag is an intermediate variable used during the block calculation.
ProSoft Technology, Inc.
September 20, 2018
Data Type
INT
INT
INT
MNETCPASSTHRU
BOOL
BOOL
MNETCINITOUTDATA
INT
BOOL
INT
Description
Holds the value of the block counts of the
WriteData array
Holds remainder calculation value from the
read array
Holds remainder calculation value from the
write array
Modbus pass-through commands
Allows setting module IP address
Allows getting module IP address
Used to bring the module into a known state
after a restart operation
Fault Code value
Check initialization trigger
Computed block offset for status data
