Reference
User Manual
Word Offset
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18 to 247
The last digit in the block identification code indicates the number of commands
to process. For example, a block identification code of 5003 indicates that three
commands are to be placed in the queue. In this case, the first three of the 16
available Command Indexes will be used to determine exactly which three
commands will be added to the queue, and to set their order of execution.
Values to enter for the 16 Command Indexes range from 0 to 15 and correspond
to the MNET Client x Command List entries, which are numbered from 1 to 16.
To determine the Command Index value, subtract one (1) from the row number
of the command in the MNET Client x Command List, as seen in the Command
Entry Formats (page 46).
The module responds to a Command Control block request with a response
block, indicating the number of commands added to the command priority queue.
Block Response from Module to Processor
Offset
0
1
2
3 to 248
249
Page 122 of 172
Modbus TCP/IP Client Enhanced Communication Module - Client/Server
Description
Command Index 2
Command Index 3
Command Index 4
Command Index 5
Command Index 6
Command Index 7
Command Index 8
Command Index 9
Command Index 10
Command Index 11
Command Index 12
Command Index 13
Command Index 14
Command Index 15
Command Index 16
Spare
Description
Reserved
Write Block ID
Number of commands added to command queue
Spare
5001 to 5016
MVI56E-MNETC/MNETCXT ♦ ControlLogix Platform
ProSoft Technology, Inc.
Length
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
230
Length
1
1
1
246
1
