MVI56E-MNETC/MNETCXT Configuration
User Manual

If the MVI56E-MNETC/MNETCXT module is located in the same rack as the
first 1756-ENBT module, select R
parameters.

If the MVI56E-MNETC/MNETCXT is available in a remote rack (accessible
through ControlNet or Ethernet/IP), include all racks (by using the A
button).
Parameter
Source Module
Source Module IP Address
Source Module Node Address
Destination Module
Destination Module Slot Number
To use the CIPconnect Path Editor, follow these steps.
1 Configure the path between the 1756-ENBT connected to your PC and the
MVI56E-MNETC/MNETCXT module.
If the module is located in a remote rack, add more racks to configure the
o
full path.
o The path can only contain ControlNet or Ethernet/IP networks.
The maximum number of supported racks is six.
o
2 Click C
ONSTRUCT
3 Click OK to confirm the configured path.
Example 1: Local Rack Application
For this example, the MVI56E-MNETC/MNETCXT module is located in the same
rack as the 1756-ENBT that is connected to the PC.
Page 56 of 172
Modbus TCP/IP Client Enhanced Communication Module - Client/Server
Description
Source module type. This field is automatically selected
depending on the destination module of the last rack
(1756-CNB or 1756-ENBT).
IP address of the source module (only applicable for
1756-ENBT)
Node address of the source module (only applicable for
1756-CNB)
Select the destination module associated to the source module
in the rack. The connection between the source and destination
modules is performed through the backplane.
The slot number where the destination MVI56E-
MNETC/MNETCXT module is located.
CIP P to build the path in text format.
ATH
MVI56E Module
Rack 1
0 1 2 3
MVI56E-MNETC/MNETCXT ♦ ControlLogix Platform
N . 1 and configure the associated
ACK O
1756-ENBT
Ethernet
R
DD ACK
ProSoft Technology, Inc.
September 20, 2018
