MVI56E-MNETC/MNETCXT ♦ ControlLogix Platform
Modbus TCP/IP Client Enhanced Communication Module - Client/Server
5

Reference

In This Chapter

Product Specifications ......................................................................... 101

Functional Overview ............................................................................ 103

Ethernet Cable Specifications ............................................................. 134

Modbus Protocol Specification ............................................................ 135

Using the Optional Add-On Instruction ................................................ 148

Adding the Module to an Existing Project ............................................ 159

Using the Sample Program ................................................................. 162
5.1

Product Specifications

The MVI56E Modbus TCP/IP Client Enhanced Communication Module -
Client/Server allows Rockwell Automation
Automation Controllers (PACs) to interface easily with Modicon Programmable
Automation Controller (PACs) , as well as multiple Modbus TCP/IP server-
compatible instruments and devices. The multi-Client module improves
performance when controlling multiple servers on a Modbus TCP/IP network, by
supporting up to 30 Clients. It also supports up to 20 server connections (10
MNET, 10 MBAP).
MVI56E enhancements include configuration and management through the
module's Ethernet port, and CIPconnect
ControlNet™ and EtherNet/IP™ networks.

5.1.1 General Specifications


Backward compatible with previous MVI56-MNETC versions

Single-slot 1756 ControlLogix backplane compatible

10/100 Mbps auto crossover detection Ethernet configuration and application
port

User-definable module data memory mapping of up to 10,000 16-bit registers

CIPconnect-enabled network configuration and diagnostics monitoring using
ControlLogix 1756-ENxT and 1756-CNB modules and EtherNet/IP pass-
through communication

ProSoft Configuration Builder (PCB) software supported, a Windows-based
graphical user interface providing simple product and network configuration

Sample ladder logic and Add-On Instructions (AOI) are used for data transfer
between module and processor

4-character, alpha-numeric, scrolling LED display of status and diagnostics
data in plain English - no cryptic error or alarm codes to decipher
ProSoft Technology, Inc.
September 20, 2018
® ®
ControlLogix Programmable
®
technology for bridging though
Reference
User Manual
Page 101 of 172
