MVI56E-MNETC/MNETCXT ♦ ControlLogix Platform
Modbus TCP/IP Client Enhanced Communication Module - Client/Server
Because the server interface device is normally serviced at the end of the
controller's scan, the data reflect the register content at the end of the scan.
Some servers limit the quantity of register content provided each scan; thus for
large register quantities, multiple transmissions are made using register content
from sequential scans.
In the example below, the registers 40108 to 40110 have the decimal contents
555, 0, and 100 respectively.
Node
Function
Address
Code
0B
03

5.4.5 Read Input Registers (Function Code 04)

Query
This function retrieves the contents of the controller's input registers from the
Modbus 3x range. These locations receive their values from devices connected
to the I/O structure and can only be referenced, not altered from within the
controller, The addressing allows retrieving up to 125 registers at each request;
however, the specific server device may have restrictions that lower this
maximum quantity. The registers are numbered for zero (30001 = zero, 30002 =
one, and so on). Broadcast mode is not allowed.
The example below requests the contents of register 30009 in server number 11.
Note: This is the structure of the message being sent out to the Modbus network. The byte values
below are in hexadecimal display.
Node
Function
Address
Code
0B
04
Response
The addressed server responds with its address and the function code followed
by the information field. The information field contains 1 byte describing the
quantity of data bytes to be returned. The contents of the registers requested
(DATA) are 2 bytes each, with the binary content right justified within each pair of
characters. The first byte includes the high order bits and the second, the low
order bits.
ProSoft Technology, Inc.
September 20, 2018
Byte
High
Low
Count
Data
Data
06
02
2B
Data Start
Data Start
Point High
Point Low
00
08
High
Low
High
Data
Data
Data
00
00
00
Data Number
Data Number
of Points High
of Points Low
00
01
User Manual
Low
Error Check
Data
Field
(2 bytes)
64
CRC
Error Check
Field
(2 bytes)
CRC
Page 139 of 172
