Product Overview

3 Product Overview

3.1 Intended Use

3 3
The drive is an electronic motor controller that converts AC mains input into a variable AC waveform output. The frequency
and voltage of the output are regulated to control the motor speed or torque. The drive is designed to:
•
Regulate motor speed in response to system feedback or to remote commands from external controllers.
•
Monitor system and motor status.
•
Provide motor overload protection.
The drive is designed for industrial and commercial environments in accordance with local laws and standards. Depending
on configuration, the drive can be used in standalone applications or form part of a larger system or installation.
NOTICE
In a residential environment, this product can cause radio interference, in which case supplementary mitigation
measures can be required.
Foreseeable misuse
Do not use the drive in applications which are non-compliant with specified operating conditions and environments. Ensure
compliance with the conditions specified in chapter 10 Specifications.

3.2 Power Ratings, Weights, and Dimensions

For enclosure sizes and power ratings of the drives, refer to Table 3.1. For more dimensions, see chapter 10.9 Enclosure
Dimensions.
Enclosure size
IP
NEMA
Shipping dimensions [mm (in)]
Drive dimensions [mm (in)]
Maximum weight [kg (lb)]
Table 3.1 Power Ratings, Weight, and Dimensions, Enclosure Sizes J8–J9, 380–480 V
6
VLT® AutomationDrive FC 361
Height
Width
Depth
Height
Width
Depth
Danfoss A/S © 06/2018 All rights reserved.
J8
20
Chassis
587 (23)
1230 (48)
460 (18)
1026.5 (40.4)
250.0 (9.8)
375.0 (14.8)
101.2 (223.1)
J9
20
Chassis
587 (23)
1430 (56)
535 (21)
1293.78 (50.9)
350.0 (13.8)
375.0 (14.8)
168.6 (376.1)
