Specifications

10.8 Fastener Tightening Torques

Apply the correct torque when tightening fasteners in the locations that are listed in Table 10.6. Too low or too high torque

when fastening an electrical connection results in a bad electrical connection. To ensure correct torque, use a torque

wrench.

Location

Mains terminals

Motor terminals

Ground terminals

Load sharing terminals

Relay terminals

Door/panel cover

Gland plate

Table 10.6 Fastener Torque Ratings

VLT® AutomationDrive FC 361

Bolt size

M10/M12

M8/M10

M10/M12

–

Torque [Nm (in-lb)]

19 (168)/37 (335)

9.6 (84)/19.1 (169)

19 (168)/37 (335)

0.5 (4)

2.3 (20)

MG06I102
