Commissioning
7.2.3 Entering System Information
NOTICE
SOFTWARE DOWNLOAD
For commissioning via PC, install MCT 10 Set-up
Software. The software is available for download (basic
version) or for ordering (advanced version, code number
130B1000). For more information and downloads, see
www.danfoss.com/en/service-and-support/downloads/dds/
vlt-motion-control-tool-mct-10/.
The following steps are used to enter basic system
information into the drive. Recommended parameter
settings are intended for start-up and checkout purposes.
Application settings vary.
NOTICE
Although these steps assume that an asynchronous
motor is used, a permanent magnet motor can be used.
For more information on specific motor types, see the
product-specific programming guide.
1. Press [Main Menu] on the LCP.
2. Select 0-** Operation/Display and press [OK].
3. Select 0-0* Basic Settings and press [OK].
4. Press [Quick Menus] on the LCP and then select
02 Quick Setup.
5. Change the following parameters settings listed
in Table 7.2 if necessary. The motor data is found
on the motor nameplate.
Parameter
Parameter 0-01 Language
Parameter 1-20 Motor Power [kW]
Parameter 1-22 Motor Voltage
Parameter 1-23 Motor Frequency
Parameter 1-24 Motor Current
Parameter 1-25 Motor Nominal Speed
Parameter 5-12 Terminal 27 Digital Input
Parameter 3-02 Minimum Reference
Parameter 3-03 Maximum Reference
Parameter 3-41 Ramp 1 Ramp up Time
Parameter 3-42 Ramp 1 Ramp Down Time
Parameter 3-13 Reference Site
Parameter 1-29 Automatic Motor Adaptation
(AMA)
Table 7.2 Quick Set-up Settings
MG06I102
Operating Guide
NOTICE
MISSING INPUT SIGNAL
When the LCP shows AUTO REMOTE COASTING or alarm
60, External Interlock, the unit is ready to operate but is
missing an input signal. See chapter 5.8.4 Enabling Motor
Operation (Terminal 27) for details.
7.2.4 Configuring Automatic Energy
Automatic energy optimization (AEO) is a procedure that
minimizes voltage to the motor, reducing energy
consumption, heat, and noise.
1.
2.
3.
4.
5.
7.2.5 Configuring Automatic Motor
Automatic motor adaptation is a procedure that optimizes
compatibility between the drive and the motor.
The drive builds a mathematical model of the motor for
regulating output motor current. The procedure also tests
the input phase balance of electrical power. It compares
Default setting
the motor characteristics with the data entered in
English
parameters 1-20 to 1-25.
4.00 kW
400 V NOTICE
50 Hz
If warnings or alarms occur, see chapter 9.5 List of
9.00 A
Warnings and Alarms. Some motors are unable to run the
1420 RPM
complete version of the test. In that case, or if an output
Coast inverse
filter is connected to the motor, select [2] Enable reduced
0.000 RPM
AMA.
1500.000 RPM
3.00 s
Run this procedure on a cold motor for best results.
3.00 s
1.
Linked to Hand/
2.
Auto
3.
Off
4.
5.
6.
Danfoss A/S © 06/2018 All rights reserved.
Optimization
Press [Main Menu].
Select 1-** Load and Motor and press [OK].
Select 1-0* General Settings and press [OK].
Select parameter 1-03 Torque Characteristics and
press [OK].
Select either [2] Auto Energy Optim CT or [3] Auto
Energy Optim VT and press [OK].
Adaptation
Press [Main Menu].
Select 1-** Load and Motor and press [OK].
Select 1-2* Motor Data and press [OK].
Select parameter 1-29 Automatic Motor Adaptation
(AMA) and press [OK].
Select [1] Enable complete AMA and press [OK].
Press [Hand On] and then [OK].
The test runs automatically and indicates when it
is complete.
7 7
