Product Overview

3.7 LCP Menus

3.7.1.1 Quick Menu Mode
The Quick Menu mode provides a list of menus used to
3 3 configure and operate the drive. Select the Quick Menu
mode by pressing the [Quick Menu] key. The resulting
readout appears on the LCP display.
0 RPM
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q5 Changes Made
Q6 Loggings
Illustration 3.5 Quick Menu View
3.7.1.2 Q1 My Personal Menu
Use My Personal Menu to determine what is shown in the
display area. Refer to chapter 3.6 Local Control Panel (LCP).
This menu can also show up to 50 pre-programmed
parameters. These 50 parameters are manually entered
using parameter 0-25 My Personal Menu.
3.7.1.3 Q2 Quick Setup
The parameters found in the Q2 Quick Setup contain basic
system and motor data that are always necessary for
configuring the drive. See chapter 7.2.3 Entering System
Information for the set-up procedures.
3.7.1.4 Q5 Changes Made
Select Q5 Changes Made for information about:
•
The 10 most recent changes.
•
Changes made from default setting.
12
VLT® AutomationDrive FC 361
0.00 A
1(1)
Danfoss A/S © 06/2018 All rights reserved.
3.7.1.5 Q6 Loggings
Use Q6 Loggings for fault finding. To get information about
the display line readout, select Loggings. The information is
shown as graphs. Only parameters selected in
parameter 0-20 Display Line 1.1 Small through
parameter 0-24 Display Line 3 Large can be viewed. It is
possible to store up to 120 samples in the memory for
later reference.
Q6 Loggings
Parameter 0-20 Display Line 1.1 Small
Parameter 0-21 Display Line 1.2 Small
Parameter 0-22 Display Line 1.3 Small
Parameter 0-23 Display Line 2 Large
Parameter 0-24 Display Line 3 Large
Table 3.7 Logging Parameter Examples
3.7.1.6 Main Menu Mode
The Main Menu mode lists all the parameter groups
available to the drive. Select the Main Menu mode by
pressing the [Main Menu] key. The resulting readout
appears on the LCP display.
0 RPM
Main Menu
O-** Operation / Display
1-** Load and Motor
2-** Brakes
3-** Reference / Ramps
Illustration 3.6 Main Menu View
All parameters can be changed in the main menu. Option
cards added to the unit enable extra parameters associated
with the option device.
Speed [RPM]
Motor Current
Power [kW]
Frequency
Reference %
0.00 A
1(1)
