Wiring Schematic - Danfoss VLT AutomationDrive FC 361 Operating Manual

Electrical Installation

5.3 Wiring Schematic

3-phase
power
input
5 5
+10 V DC
0 to +10 V DC
0/4-20 mA
0 to +10 V DC
0/4-20 mA
Illustration 5.2 Basic Wiring Schematic
20
VLT® AutomationDrive FC 361
91 (L1)
92 (L2)
93 (L3)
95
PE
Switch mode
power supply
10 V DC
15 mA
50 (+10 V OUT)
+ -
A53 U-I (S201)
53 (A IN)
ON=0/4-20 mA
A54 U-I (S202)
OFF=0 to ±10 V
54 (A IN)
55 (COM A IN)
12 (+24 V OUT)
13 (+24 V OUT)
P 5-00
24 V (NPN)
18 (D IN)
0 V (PNP)
24 V (NPN)
19 (D IN)
0 V (PNP)
20 (COM D IN)
24 V (NPN)
27 (D IN/OUT)
0 V (PNP)
24V
0V
24 V (NPN)
29
(D IN/OUT)
0 V (PNP)
24V
0V
24 V (NPN)
32 (D IN)
0 V (PNP)
24 V (NPN)
33 (D IN)
0 V (PNP)
Danfoss A/S © 06/2018 All rights reserved.
(U) 96
(V) 97
(W) 98
(PE) 99
Regen +
(R+) 82
24 V DC
200 mA
+ -
Regen -
Relay1
Relay2
(COM A OUT) 39
(A OUT) 42
S801/Bus Term.
OFF-ON
ON=Terminated
OFF=Open
5V
S801
RS485
(P RS485) 68
interface
(N RS485) 69
(COM RS485) 61
Motor
Regen
83
03
240 V AC, 2A
02
400 V AC, 2A
01
06
240 V AC, 2A
05
400 V AC, 2A
04
Analog output
0/4-20 mA
0V
RS485
(PNP) = Source
(NPN) = Sink
MG06I102
