APV
APV_SV1_UK-8_082017.qxp
Fig. 5.4.
CU4
control unit
Fig. 5.5.
1
2
4
3
5
6
9
Butterfly Valve
DELTA SV1
IInstruction Manual: UK - rev. 8
5.
Auxiliary Equipment
5.4.
Control unit (CU, fig. 5.4.)
Units with feedback switch and magnet valve for the pneumatic
control of the valve for assembly on the actuator are also available
in fieldbus technology.
The assembly of a control unit on a pneumatic actuator
is possible.
The following different designs are available:
CU3
Direct Connect
control unit
AS-i extended
62 slaves
DeviceNet
Profibus
5.5.
Adapter for control unit (fig 5.5.)
CU31 Profibus, CU31 DeviceNet
The following adapters are required to install the control unit
on the SV1 valve.
Item
-
1
2
3
- 4
- 5
7 *
- 6
8
7*
8
9
Spare parts for CU2 adapter
Pcs.
Designation
-
CU2 adapter K080 SVS1F, DKR
1
CU operating cam cpl. SVS/DKR
3
cyl. screw ISO1207-M5x18-A2-7
1
adapter set
1
o-ring 88,62-1,78 NBR
2
o-ring 5,28-1,78 NBR
1
CU adapter for SVS,DKR
o-ring 90-2 NBR
1
* scope of supply actuator
1
o-ring 13,0-2,0 NBR 70
2
blind plug G1/8"
CU41-T-Direct Connect
08 - 45 - 101/93; H320461
CU41-T-AS-i extended
08 - 45 - 111/93; H320468
CU31 DeviceNet
16 - 31 - 240/93; H209422
CU31 Profibus
08 - 45 - 001/93; H315495
reference No.
ID - No.
000 08-48-416/93
H209431
000 08-60-779/93
H208853
000 08-60-760/15
H208835
000 08-60-333/93
H310442
000 58-06-387/83
H208639
000 58-06-044/83
H208640
000 08-60-728/93
H208803
000 58-06-426/83
H143352
000 58-06-049/83
H208642
000 08-60-740/93
H208815
UK
