APV
APV_SV1_UK-8_082017.qxp

Table of Contents

1. General Terms
2. Safety Instructions
3. Intended Use
4. Mode of Operation
4.1. General Terms
5. Auxiliary Equipment
5.1. Valve position indication - actuated valve
5.2. Valve position indication - manually operated valve
5.3. Handle with adjusting device
5.4. Control Unit
5.5. Adapter for control unit
5.6. Turning actuator for control unit
6. Cleaning
7. Installation
7.1. Connections
7.2. Welding Instructions
8. Dimensions / Weights
9. Technical Data
9.1. General Data
9.2. Compressed air quality
9.3. Kvs - values
9.4. Opening / Closing times
9.5. Torques
9.6. Control air consumption
10. Materials
11. Maintenance
12. Service Instructions
12.1. Disassembly from the line system
12.2. Disassembly of actuating device
12.3. Dismantling of inner parts
12.4. Replacement of seals
12.5. Installation of seals and bearing bushes
12.6. Installation of actuating device
12.7. Installation of proximity switches
13. Spare Parts Lists
(see attachment)
SV1 - FZ CU DN 25 - 100, 1"-4"
SV1 - H DN 25 - 100, 1"-4"
Handle SV-HL valve position indication
DN25 - 100, 1" - 4"
Turning actuator K-80, K-125, K-180 F/L
Turning actuator spring/air for feedback unit
Butterfly Valve
DELTA SV1
Instruction Manual: UK - rev. 8
UK
Page
2
2 - 3
3
4
5 - 7
8
8 - 9
10 - 11
12 - 13
14
15
16 - 18
19
- RN 01.037 - 14
- RN 01.037.5 - 9
- RN 01.037.0
- RN 01.073
- RN 01.076
1
