APV
APV_SV1_UK-8_082017.qxp
13
9.
Technical Data
9.4.
Opening and closing times
The actuating times depend on the length of the air line between
the magnet valve to the air control and the actuator.
For air lines with a length of up to 1 m, the opening time for
butterfly valves DN 25/1" to DN 100/4" at 6 bar control air pressure
amounts to about 1 second. The closing time, after air shut-off,
depends on the nominal dimension and amounts to 2 to 3
seconds.
If the valves are subject to strong friction, e.g. through dry seals,
the actuating times extend accordingly.
9.4.1. Opening and closing times for butterfly valves
The opening and closing times of valves
equipped with a control unit can be adjusted.
DN
Inch
25
1"
40
1,5"
50
2"
65
2,5"
80
3"
100
4"
All time data are approximate values taken from
sample measurements.
9.5.
Torque Md [Nm] for butterfly valves
DN
25
40
50
65
80
100
9.6.
Control air consumption
at 6 bar control pressure
turning actuator K080 (spring/air)
per stroke 1,8 (NL)
opening time in sec.
control air pres. 6bar
hose length 1 m
1 sec.
1 sec.
1 sec.
1 sec.
1 sec.
1,2 sec.
Inch
Md [Nm]
1"
10
1,5"
12
2"
16
2,5"
20
3"
22
4"
24
UK
closing time in sec.
1,5 sec.
1,5 sec.
1,5 sec.
2,5 sec.
3,0 sec.
3,5 sec.
Butterfly Valve
DELTA SV1
Instruction Manual: UK - rev. 8
