5.

Auxiliary Equipment

5.1. Valve position indication - valve with pneumatic actuator
Proximity switches to signal the limit position of the valve disc
can be installed in the yoke area if required.
We recommend to use our APV standard proximity switches.
Type: three-wire proximity switch (ref.-No. 08-60-011/93; H16223)
Operating distance: 4mm / diameter: 11mm / length: 30 mm.
Feedback complete with support and proximity switch
(ref.-No. 15-33-023/93; H327725) for a limit position.
Using a valve position indicator other than APV, we cannot accept
any liability for faulty function.
5.2. Valve position indication - valve with manual operation
Specific manual actuations with feedback feature are available:
a) Feedback of the disc position closed
(simple variant).
b) Feedback of both disc positions
open and closed is possible.
5.3. Manual operation with adjusting device
As a special design, a handle is available which provides for the
fixation of intermediate positions beside the two limit positions.
