5.

Auxiliary Equipment

5.1 Valve position indication / proximity switch
- The pneumatic actuator is equipped with one or two electric position
switches (proximity switches) to indicate the current valve position.
feedback of valve position
by proximity switch (PSH1)
5.2 Valve position indication / micro switch
- The pneumatic actuator can be equipped with an electric position
switch (proximity switch) to indicate the current valve position.
feedback of valve position by
two proximity switches (PSH2)
feedback of valve position
by two micro switches
