SBC82400 ISA Half-Size CPU Board Series User's Manual
2.4.6 Compact Flash Connector: CN9
The SBC82400 is equipped with a CompactFlash socket on the
solder side and it supports the CompactFlash through the IDE2
interface. The socket itself is especially designed to prevent
any incorrect installation of the CompactFlash card.
When install or remove the CompactFlash card, please make
sure that the system power is off.
The CompactFlash card is defaulted as the E: or F: disk drive
in the computer system.
Jumpers and Connectors
16
