SBC82400 ISA Half-Size CPU Board Series User's Manual
Date
The date format is <day>, <date> <month> <year>. Press <F3> to
show the calendar.
The day of week, from Sun to Sat, determined by
day
the BIOS, is read only
The date, from 1 to 31 (or the maximum allowed
date
in the month), can key in the numerical / function
key
month The month, Jan through Dec.
year The year, depends on the year of BIOS
Time
The time format is <hour> <minute> <second> accepting either
functional key or numerical key. The time is calculated based on
the 24-hour military-time clock. For example, 1 p.m. is 13:00:00.
IDE Primary Master/Primary Slave
This category identifies the type of the channel that is installed in
the computer. There are 45 predefined types and 2 user definable
types for Enhanced IDE BIOS. Type 1 to Type 45 is predefined.
Type User is user-definable.
Press <PgUp>/<+> or <PgDn>/<−> to select a numbered hard disk
type or type the number and then press <Enter>. Note that the
specifications of the drive in the system must match with the drive
table. The hard disk will not work properly if the improper
information within this category is entered. If the disk drive type
does not match or is not listed, the Type User is used to define the
drive type manually.
If the Type User is selected, related information has to be entered.
Enter the information directly from the keyboard and press <Enter>.
This information should be provided in the documentation from the
hard disk vendor or the system manufacturer.
If the controller of HDD interface is ESDI, select "Type 1".
If the controller of HDD interface is SCSI, select "None".
If the controller of HDD interface is CD-ROM, select "None".
Award BIOS Utility
31
