SBC82400 ISA Half-Size CPU Board Series User's Manual
1.2

Secpifications

CPU
Onboard STPC Consumer-II microprocessor
System Chipset
Integrated in Consumer-II
Cache memory
Integrated L1 8Kbyte write back cache
System memory
128MB maximum
First bank: onboard 32MB
Second bank: one 168-pin DIMM socket supporting
up to 128MB SDRAM
BIOS
AWARD BIOS, Plug-and-Play 2Mbit Flash ROM with
integrated Ethernet Novell RPL and Windows PXE Boot
ROM functions
Onboard IDE
1 channel up to 2 devices
PIO Mode 0-4, DMA Mode 0-2
Standard I/O:
Two serial ports, including one RS-232 and one RS-
232/422/485
One parallel port, SPP/EPP/ECP
One HDD Interface
One FDD Interface
One PS/2 Keyboard & Mouse Interface
One IrDA interface for wireless communication
Watchdog Timer
Generates a system reset or NMI by jumper
selectable
Software programmable time interval
64 levels, 0.5~8/5~80/50~800/100~1600 seconds
