SBC82400 ISA Half-Size CPU Board Series User's Manual

2.4.10 Serial Port Interface: COM1 and COM2

The SBC82400 has two onboard serial ports: COM1 is RS232
and COM2 is RS-232/422/485, jumper selectable. Both ports
feature +5V/+12V power capability on pin 1 and pin 8,
depending on the jumper setting
2.4.10.1 RS-232 Connectors
The RS-232 pin assignment is listed on the following table.
Pin Description
1
Data Carrier Detect (DCD)
3
Receive Data (RXD)
5
Transmit Data (TXD)
7
Data Terminal Ready (DTR)
9
Ground (GND)
2.4.10.2 RS-422/485 Connectors
The RS-422/485 pin assignment for COM2 is listed below.
Pin #
1
2
3
4
5
6
7
8
9
10
Jumpers and Connectors
Pin Description
2
Data Set Ready (DSR)
4
Request to Send (RTS)
6
Clear to Send (CTS)
8
Ring Indicator (RI)
10
NC
Signal Name
R2-422 RS-485
TX- DATA-
r
NC NC
TX+ DATA+
NC NC
RX+
NC
NC NC
RX-
NC
NC NC
GND GND
NC NC
2
1
3 4
6
5
8
7
9
10
21
