SBC82400 ISA Half-Size CPU Board Series User's Manual

4.2.1 Standard CMOS Setup

"Standard CMOS Setup" is used to record some basic hardware
configurations in the computer system and set the system clock
and the error handling. If the motherboard is already installed in
a working system, there is no need to enter this option. However,
the Standard CMOS option has to be setup in any of the
following situations: the system hardware configurations are
changed, the onboard battery fails, and the configuration stored
in the CMOS memory is lost or damaged.
Phoenix – AwardBIOS CMOS Setup Utility
Standard CMOS Features
Date (mm:dd:yy)
Time (hh:mm:ss)
IDE Primary Master
IDE Primary Slave
IDE Secondary Master
IDE Secondary Slave
Drive A
Drive B
Halt on
Base Memory
Extended Memory
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F7: Optimized Defaults
At the bottom of the menu, the control keys are for the use of
this menu. The <F1> key can be pressed in each item field to
display the relevant information for help. The memory display at
the lower right-hand side of the menu is read-only. It will adjust
automatically according to the memory changed. The following
pages describe each item of this menu.
30
Wed, Aug 7 2002
13 : 9 : 11
None
None
None
None
1.44M, 3.5 in.
None
All, But keyboard
640K
65535K
Award BIOS Utility
Item Help
Menu Level
Change the
Day, month,
Year and
Century
