6.5 Control board:
CATRAX Automatic Plus's control board was designed to meet most technologies of
access control terminals in the market. The controller have mechanical features and
layout perfectly suited for the CATRAX Automatic Plus's needs and it is one of the best
options for the equipment's operation.
The following images show the control board with its straps, connectors, and
dipswitch, as well as the location of the power supply and the control board in CATRAX
Automatic Plus.
The table below describes the functions of the control board's connectors:
Con ector CN8
n
Con ector CN9
n
Ds01
Ds02
20
