digicon catrax automatic plus Product Manual page 21

Si nal g N ame /Descri
CN1
BOX SENSOR
1 LED anode
Box signal
2
3 GND
GND
4
CN2 JTAG - Inner use
CN3 SERIAL RS - 232
2 TX
3 RX
5 GND
CN4 ENGINE
1 DAT + E
2 DAT - E
3 GND_485
4 (+) 24V_EXT
5 GND
CN5 POWER - POWER INPUT
1 (+) 24Vcc
2 GND
3 (+) 24Vcc
CN6 TURNSTILE SENSORS
1 Sensor 1 signal
2 LED 1 anode
3 sensor 2 signal
4 GND
5 LED 2 anode
CN7 AUDIO
1 SI NAL G
2 GND
CN8 INPUTS
+Vext1 (enables turn through voltage)
1
HAB1 (enables turn through dry contact - from right to left)
2
GND
3
Vext2 (enables turn through voltage)
4
HAB2 (enables urn through dry contact - from left to right)
5
GND
6
+24Vcc (avalable to auxiliary - maximum 500mA)
7
Vext3 (enables turn through voltage)
8
BQC (activates anti-panic system)
9
GND
10
Output for yellow pictogram
11
NC
12
NO or NC contact (bob return)
13
C Contact (bob return)
14
NO or NC contact (BQC return)
15
contact C (BQC return)
16
ption
21
