Then, assemble the upper panel's rear cover. The image below shows the parts
corresponding to each phase.
Frontal plastic
cover set
Front stainless
steel sheet
Collecting box's
socket kit
Front Cover:
Rear cover:
Flat washer M3,
spring washer M3
and hex nut M3
Rear stainless steel cover
Pictogram's acrylic
