digicon catrax automatic plus Product Manual page 22

OUTPUTS
CN9
1
NO or NC Contact (HAB1 return)
2
Contact C (HAB1 return)
3 NO or NC Contact (HAB2 return)
4
Contact C (HAB2 return)
5
Output for indicative X (open collector NPN – maximum 500 mA) orange wire
6 Output for arrow > (open collector NPN – maximum 500 mA) blue wire
7 Output for arrow < (open collector NPN – maximum 500 mA) green wire
8
+24Vcc (indicative arrows' power) red wire
9
GND (indicative arrows' power) black wire
10 + solenoid of badge collector box
11
- solenoid of badge collector box
12
Sound signal (open collector – NPN)
CN10 SOL BQC
1 (+) 24Vca
2 SI NAL G
CN14 BQC SENSOR
1 (+) 24Vca
2 SI NAL G
CN18 ELETROÍMÃS
1 (+) ele
2 ( ) ele -
3 (+) ele
4
( ) ele -
INFORMATION:
- The engine (CN4) and electromagnets (CN18) cables are provided
alongside CATRAX Automatic Plus.
The following sections concern important aspects of CATRAX Automatic Plus's control
board configuration and connections of CATRAX Automatic Plus.
ctromagnet 1
ctromagnet 1
ctromagnet 2
ctromagnet 2
22
