6.3 Power Supply:

Among the main advantages of this optional item, is its adaptation capability to
the voltage variations often found in installation sites – the input voltage can
vary between 100 and 240 Vca.
The supply's specific technical features, protections and dimensions were
carefully tested and approved in hostile temperature and environmental
conditions, which ensures the adequate power supply to the equipment's
performance. Besides the input and output voltages indicated in the image
below, the supply has a short-circuit and overheating protection.
INPUT:
100 TO
240 VCA
SAÍDA
6.4 Kit contador eletromecânico
Among the main advantages of this optional item, is its adaptation capability to
the voltage variations often found in installation sites – the input voltage can
vary between 100 and 240 Vca.
The supply's specific technical features, protections and dimensions were
carefully tested and approved in hostile temperature and environmental
conditions, which ensures the adequate power supply to the equipment's
performance. Besides the input and output voltages indicated in the image
below, the supply has a short-circuit and overheating protection
Technical characteristics:
Power supply: 24 Vcc
Number of digits: 06 (no return to zero)
Digits size: 5 x 2 mm (height x width)
PHASE:
NEUTRAL
GROUND
WIRE
GND
24V cc / 3A
.
