14 Operation METPOINT
The operation is self-explanatory to the largest possible extent and is menu-driven via the touch panel.
The selection of the respective menu items is realised via short "tapping" with the finger or using a soft-
pointed pen.
Caution: Please do not use pens or other objects with sharp edges!
The foil may be damaged!
After the connection of the sensors, the latter also need to be configured.
Entries or changes can be made in all the fields with a white background.
The measured values can be displayed as a curve or as values.
Words in
green letters
portant menu paths or menu items are marked in
The menu navigation is generally shown in
The table of contents and the chapter references in
headers.
14.1 Main menu (home)
You can go to every available sub item via the main menu.
14.2 Initialisation
Please select the suitable configurations in Chapter
34
®
BDL compact
mainly point to the illustration(s) in the chapter section.
green
Operation METPOINT® BDL compact
green
letters.
letters!
blue letters
contain links to the respective chapter
Subsequent to the switching-on of the
®
METPOINT
BDL compact, all channels are
initialized and the main menu appears.
Caution:
At the first start-up, channels may not be
preset.
12.2.2 Sensor settimgs
But also related im-
and set them!
