12 Connection diagrams of the different sensor types

As regards consumption and dew point sensors, there is the possibility to provide the measured values
as an analogue current signal 4 – 20 mA for further processing . In the connection diagrams, the collec-
tion of the current signal for an external PLC/central control system or for an external display is ex-
plained.
When using the connecting leads BEKO 4014064 or 4014065, the following pin assignment needs to
be observed:
SD21
Connecting plug
Connecting lead
4025252 (5m)
SD23 (4 - 20 mA)
Connecting plug
Connecting lead
4025253 (5m)
SD23 (0 - 10 V)
Connecting plug
Connecting lead
4025253 (5m)
SD23 (RS 485)
Connecting plug
Connecting lead
4025253 (5m)
SP21/ SP61
Connecting plug
Connecting lead
4025252 (5m)
SP22/SP62
Connecting plug
Connecting lead
on request
FS109 /FS211/
DP109
Connecting plug
Connecting lead
4014064 (5m)
24
Connection diagrams of the different sensor types
PIN 1 PIN 2
+ U Not used
V
brown
PIN 1 PIN 2
+ U
Not used
V
brown
PIN 1 PIN 2
+ U +U
V OUT
brown white
PIN 1 PIN 2
+ U Not used
V
brown
PIN 1 PIN 2
+ U Not used
V
brown
PIN 1 PIN 2
+U GND
V
brown black
PIN 1 PIN 2
SDI - U
V
brown white
PIN 3 PIN 4
+I Not used
OUT
blue
PIN 3 PIN 4
+I
Not used
OUT
white
PIN 3 PIN 4
GND Not used
Black
PIN 5 PIN 6
- U Not used
V
blue
PIN 3 PIN 4
+I Not used
OUT
blue
PIN 3 PIN 4
- U -U
V OUT
blue white
PIN 3 PIN 4
+ U +I (500
V
µA)
blue black
PIN 5 PIN 6
Not used Not used
PIN 5 PIN 6
- U GND
V
blue black
PIN 5 PIN 6
- U Not used
V
blue
PIN 7 PIN 8
Bus A (+) Bus B (-)
white black
PIN 5 PIN 6
Not used Not used
PIN 5 PIN 6
Not used Not used
PIN 5 PIN 6
Not used Not used
grey
