12.3 Analogue 2-wire, 3-wire, and 4-wire current signal
28
Connection diagrams of the different sensor types
Sensors with 4 - 20 mA output in 2-wire technology
METPOINT
®
METPOINT
BDL compact with an external trans-
Ensure that the electric circuit is closed in any case.
(e.g. pressure sensors 1.6/16/40/100/250/400 bar or
temperature sensors with an integrated transducer 4-
20mA)
®
BDL compact
mission
METPOINT® BDL compact
