44
3. Position the module vertically on the backplane and push it in carefully on the lower guide
Fig. 4.20: Mounting the module
Fig. 4.21: Centering above the connection plug
HBM
rail back up to the stop.
Upper screwed clamping gland
a.f. 4.0
Lower screwed clamping gland
BPX001 Backplane
Guide rails
QuantumX
