Software

3 Software
The supplied QuantumX System CD contains a powerful software package consisting of the
QuantumX Assistant, Lab View library, programming library for .NET/COM, TEDS-Editor,
FireWire driver as well as a program for module firmware updating. catman[EASY and
DIAdem driver are software products that can be obtained as separate product packages.
3.1

QuantumX Assistant

The HBM software "QuantumX Assistant" offers the following functions:
System..
•
Modules:
•
•
•
•
•
Channels/sensors:
•
•
•
•
Individual signals:
•
Measured values (Scope):
•
•
•
Functions and outputs
•
Sensor database
•
•
QuantumX
Create survey (modules, host PC)
Search and configuration (e.g. TCP/IP communication), naming
Reset to factory settings
Read factory calibration certificate
Analysis (information, status, log file)
Save configuration to operating PC
Configuration (name, connection type, TEDS, semi-automatic assignment)
Measurement (alphanumeric display)
Open the TEDS editor and read/write to TEDS
Activate/deactivate isochronous operation via FireWire
Set sampling rate and filter (type, cut-off frequency)
Start/Stop continuous graphic measurements (time frames, trigger, zoom)
Basic signal analysis (X-Y cursor)
Record measurements
Generate new signals using mathematics functions (peak value, rms value, adding and
multiplying, rotation)
Output signals (scaled, filteresd)
Modify and expand existing sensor databases (e.g. own sensors, dbc data files)
