Connection
6.11.25
SSI protocol
Supported by modules: MX840, MX840A, MX440A
QuantumX
1)
1)
Schematic diagram
SSI
f
= Data (−)
1 (−)
f
= Data (+)
1 (+)
f
= Shift clock (−)
2 (−)
f
= Shift clock (+)
2 (+)
Adjustable sensor supply:
Ground
f
(−)
1
f
(+)
1
f
(−)
2
Cable shield
f
(+)
2
Pin 12:
5 V ... 24 V
Pin 11:
0 V
139
6
1
11
5
15
10
6
5
10
7
Hsg.
8
9
4
Hsg. = housing
